HONDA MOD FLIP SHELL - insTALLATION VIDEOS

Overview - Case Disassembly and Assembly

Encased switchblade mechanism means no spring winding and flawless remote conversion

Remotes with SEPARATE chip and electronics - chip transfer procedure is required (and shown in video)

Remotes with separate chip and electronics include the following FCC ID's (which can be found on the back part of your remote): OUCG8D-380H-A, CWTWB1U545, and MLBHLIK-1T.

If your remote has any of the above FCC ID's, you MUST remove your chip and install it into the rectangular chip space in the flip key mod. Chip space is on top right of back part (as shown in 3rd Amazon product photo). Direction of chip is not important but should be fastened using double sided tape. Once installed, refer to the next video.

Remotes with INTEGRATED chip and electronics

Remotes with an integrated transponder chip include the following FCC ID's: (which can be found on the pack part of your remote): KR55WK49308, N5F-A05TAA, and NSF-S0084A

No chip removal is required if your remote has one of the FCC ID's above. Simply install your electronics into the mod shell as shown in the above video.
